The combination of traditional electrocardiography and advanced computer-assisted signal processing methods emancipates the physician from a considerable part of routine work.

• Complete ECG assessment cycle from filling up a patient card to issuing a competent medical conclusion.
• 22-bit ADCs and powerful digital filtering of cardiac signals allow for a high-quality ECG recording during an unlimited time.
• Beat-to-beat monitoring of ECG indices (i.e. HR, QT, PQ, ST-segment elevation, etc.) is performed simultaneously with the raw ECG recording to support a detailed index interrelationship and variability analysis either over the entire ECG examination or in individual functional tests.
• Analysis of QT dispersion represented by beat-to-beat variability, scatter gram and histogram plots helps to evaluate risk of sudden cardiac death.
• Syndrome Assessment Report is automatically generated on the basis of normality criteria.
• Study Report is automatically generated with a description of selected ECG parameters measured at the initial state and in particular ECG tests.
• Spectral Analysis with calculation of spectral plots and tables of spectral indices helps to reveal modulating effects in ECG data.
• Statistic Analysis with generation of histograms, scatter grams and tables of statistic indices for any time-amplitude ECG parameters.
• Age-related Norm Catalogs for any qualitative ECG parameters are easily created and edited by user.
• ECG Study Catalog allows for networked multistation examinations using a single patient database: with centralized report generation and distributed data storage system operation option. Advanced data search capabilities using any user-defined criteria.

ANCAR-131 cardioanalyser is intended for use in diagnostic, rehabilitative and cardiologic centers, health resorts, functional diagnosis and intensive care units of various medical institutions, in MChS (Ministry for Extraordinary Situations) service and emergency care for a wide range of clinical, research and educational purposes..

• Patient Module
• IB-2-USB Interface Unit (for communication between the patient module and PC);
• Set of Electrodes, Sensors, Cables and Accessories;
• Ancar-131 Software (CD-ROM disk), Procedure Manual and Help System for OS Windows 98/2000;
• PC (Pentium III, Athlon, Celeron, etc.) or similar NoteBook PC (for mobile applications), Monitor, Printer.

• ECG Amplifier:
  12 ECG leads
  CMRR (Common Mode Rejection Ratio): 90 dB or better.
  Resolution: 2 mcV.
  Input Range: 8 mV
  Filter Passband: 0.05 Hz 100 Hz.
  Noise Level: 20 mcV(p-p) max;
  Defibrillator Protection: Input circuits are protected against high voltage defibrillator pulses.
• DSP Block:
  ADSP-2181 processor, RS-133.
  Sampling rate: 1000 Hz
  22-bit ADC with 16-bit output word
  Baseline stabilizer: HF-FIR, zero-phase.
• Built-in calibration signal generator.
• Electrode attachment check.
• Computer Interface via USB-port.
• Automatic testing of cardiograph technical parameters
• Dimensions: 172x80x25 mm.
• Weight: 500g or less.
• Power Supply: AC 220V/50Hz, 15VA max.

• Simultaneous monitoring and recording of up to12 standard ECG leads.

• 6 ECG Recording Techniques:
  - Standard 12-lead ECG system
  - Nab's bipolar chest leads system (Nab's small triangle)
  - Bipolar orthogonal leads system
  - Frank's leads system
  - McFee-Parungao leads system
  - 1-channel recording for Heart Rate Variability (HRV) Analysis.

• Lead selection control.

• Sensitivity and sweep speed control.

• Noice filter (AC notch & tremor filter); baseline correction.

• Determination of electric cardiac axes.

• ECG waveform analysis, automatic ECG marking with following manual edition.

• Conversion of 12 standard leads into X,Y,Z axial leads for a chosen cardiac cycle; calculation of numeric indices; construction of VCG in three projections.

• Sound indication of detected R-wave to estimate heart rate dynamics by ear.

• Export of the ECG study data and calculated time-amplitude ECG indices in ASCII format.

• Print Manager helps to prepare and print multipage documents in any convenient form.

• Printing to various types of printers on ordinary paper.

• Software for Autonomic Nervous System Balance Assessment using the HRV analysis procedure based on HRV International Standard (1996).

• Automatic generation of ANS Tonus/Reactivity Study Report.

• ECG Stress-Tests: with the availability of a veloergometer, the user may arrange a fully functional veloergometry complex.

• Pattern Approval Certificate of Measuring Instruments


• Certificate of Compliance


• RF Certificate of Registration
